25.6V 100Ah LiFePO4 Battery
BAMBOO 25.6V 100Ah lithium iron phosphate battery is designed to replace Flooded, AGM, and Gel cell lead acid batteries in applications such as UPS Backup, electric power systems, communication power supply, electric scooter, RV, golf cart, marine and solar. Compared to lead-acid, Lithium Iron Phosphate batteries are extremely light, have much lower self-discharge, do not sulfate, charge much quicker, offer many more cycles and are environmentally friendly. The battery has a built-in BMS ( battery management system) which provides complete protection and balancing of the cells in the battery.
We believe you will be impressed with the quality of our lithium batteries.
- Over 2000 cycles life at 100% DOD
- Saving 50-70% weight
- Maintenance free
- Less than 3%/month self discharging
- 100% usable capacity
- Wider Temperature Range: -20 to 60 ℃
- Over-charging, over-discharging, over-current protection
- High temperature, short circuit protection
| 25.6V 100Ah | |
|---|---|
| Nominal Voltage | 25.6V |
| Nominal Capacity | 100Ah |
| Energy | 2560.0Wh |
| Internal Resistance | ≤80mΩ |
| Cycle Life | >2000 cycles @100%DOD |
| Limited Charge Voltage | 29.4±0.2V |
| Charge Method | CC/CV |
| Standard Charge Current | 0.2C |
| Max Charge Current | ≤1C |
| Discharge Cut-off Voltage | 20.0V |
| Max. Continuous Discharge Current | 100A |
| Dimension | 522*240*224mm |
| Weight | 25.0Kg |
| Case Material | ABS |
| Charge Temperature Range | 0~45℃ |
| Discharge Temperature Range | -20~60℃ |
| Self-Discharge Rate | ≤3%/month |
| Recommended storage temperature | 15~35℃ |
| Recommended storage humidity | 45%RH~75%RH |
